首頁進口晶振日本大真空晶振計時晶振32.768K,1TJF0SPDJ1AI00S,DST310S,3215mm,10pF,20ppm

計時晶振32.768K,1TJF0SPDJ1AI00S,DST310S,3215mm,10pF,20ppm

產品型號：85238239
頻率：32.768KHz
尺寸：3.2x1.5mm
產品介紹：計時晶振32.768K,1TJF0SPDJ1AI00S,DST310S,3215mm,10pF,20ppm，日本進口晶振，KDS大真空型號DST310S，編碼為1TJF0SPDJ1AI00S，是一款小體積晶振尺寸3.2x1.5x0.75m...

計時晶振32.768K,1TJF0SPDJ1AI00S,DST310S,3215mm,10pF,20ppm，日本進口晶振，KDS大真空型號DST310S，編碼為1TJF0SPDJ1AI00S，是一款小體積晶振尺寸3.2x1.5x0.75mm封裝，表面貼裝音叉型水晶振動子，頻率為32.768KHz鐘表晶振，兩腳貼片晶振，石英晶振，石英晶體諧振器，無鉛環保晶振，SMD音叉型石英振子，具有超小型，輕薄型，高精度，高可靠性，耐熱及耐環境特點，石英晶振應用于：移動通信設備，PDA，電波時鐘，鐘表電子，儀器儀表設備，智能手機，平板電腦，數字家電等應用。

計時晶振32.768K,1TJF0SPDJ1AI00S,DST310S,3215mm,10pF,20ppm，參數表

料號	DST310S
頻率范圍	32.768KHZ
負載電容	12.5pf
勵振ベ	10μW (200μW max.)
周波數偏差	±30×10−6,±50×10−6,±100×10−6 (at 25℃）
直列抵抗	300Ωmax	200Ωmax	150Ωmax	120Ωmax	100Ωmax
周波數溫度特性	±50×10−6/ー40～+85℃ (Ref. to 25℃ )
	±100×10−6/ー40～+125℃ (Ref. to 25℃ )
	±200×10−6/ー40～+150℃ (Ref. to 25℃ )
保存溫度范圍	ー40～150℃
信頼性仕様	AEC-Q200
標準包裝	3000/pcs

計時晶振32.768K,1TJF0SPDJ1AI00S,DST310S,3215mm,10pF,20ppm，尺寸表

計時晶振32.768K,1TJF0SPDJ1AI00S,DST310S,3215mm,10pF,20ppm，32.768K系列產品本身具有體積小,厚度薄,重量輕等特點,此音叉型石英晶體諧振器,晶振產品本身具備優良的耐熱性,耐環境特性,在辦公自動化,家電領域,移動通信領域可發揮優良的電氣特性,符合無鉛標準,滿足無鉛焊接的回流溫度曲線要求,金屬外殼的石英晶振使得產品在封裝時能發揮比陶瓷晶振外殼更好的耐沖擊性能.

大真空晶振	原廠代碼	型號	尺寸	頻率	負載/電壓
KDS晶振	TJF080DP1AA003	DST310S	3215	32.768KHz	8PF
KDS晶振	1TJF080DP1AA003	DST310S	3215	32.768KHz	8PF
KDS晶振	1TJF0SPDJ1AI00S	DST310S	3215	32.768KHz	10.0PF
KDS晶振	1TJF080DP1AI00P	DST310S	3215	32.768KHz	8PF
KDS晶振	1TJF090DP1AI007	DST310S	3215	32.768KHz	9PF
KDS晶振	1TJF0SPDP1AI008	DST310S	3215	32.768KHz	10.0PF
KDS晶振	1TJF125DP1AI009	DST310S	3215	32.768KHz	12.5PF
KDS晶振	1TJF090DP1AA00L	DST310S	3215	32.768KHz	9PF
KDS晶振	1TJF080DP1AA00K	DST310S	3215	32.768KHz	8PF
KDS晶振	1TJF0SPDP1AA00G	DST310S	3215	32.768KHz	10.0PF
KDS晶振	1TJF0SPDN1A000B	DST310S	3215	32.768KHz	10.0PF
KDS晶振	7BD03276A2F	DST310S	3215	32.768KHz	12.5PF
KDS晶振	1TJF090DP1AI043	DST310S	3215	32.768KHz	9PF
KDS晶振	1TJF090DP1A000A	DST310S	3215	32.768KHz	9PF
KDS晶振	1TJF090DP1AI067	DST310S	3215	32.768KHz	9PF
KDS晶振	1TJF125DP1A000A	DST310S	3215	32.768KHz	12.5PF
KDS晶振	1TJF125DP1AI115	DST310S	3215	32.768KHz	12.5PF
KDS晶振	1TJF125FP1A000A	DST310S	3215	32.768KHz	12.5PF
KDS晶振	1TJF125DP1AI00P	DST310S	3215	32.768KHz	12.5PF
KDS晶振	1TJF125DP1AI001	DST310S	3215	32.768KHz	12.5PF
KDS晶振	1TJF125DP1A00A	DST310S	3215	32.768KHz	12.5PF
KDS晶振	1TJF0SPDN1AI00A	DST310S	3215	32.768KHz	7pF
